In this video learn quickly about vector addition and vector subtraction
Show More Show Less View Video Transcript
0:00
in this video we will talk about vector
0:02
addition and Vector subtraction now to
0:06
understand the addition of two vectors
0:07
let us consider two vectors A and B that
0:11
lie in the same plane or I shall say
0:13
that both these vectors A and B are
0:15
c-liner as can be seen in this figure
0:18
now you must note that here the lengths
0:20
of the line segment representing these
0:22
vectors are proportional to the
0:24
magnitude of the vectors now to find the
0:26
sum of these two vectors you would have
0:29
to place vector B so that its tail is at
0:32
head of vector a as shown in this figure
0:35
after this join the tail of vector a to
0:38
the head of vector b as can be seen from
0:41
the figure this line o q represent
0:44
Vector C which is equal to the sum of
0:47
both vectors A and B so here we have
0:51
Vector C = A + B this procedure of
0:54
vector addition where two vectors and
0:56
their resultant from three sides of a
0:59
triangle is known as triangle method of
1:02
vector addition let us learn more about
1:04
vector addition now vector addition is
1:07
commutative that is if we find the
1:10
resultant of b + a then we obtain the
1:13
same resultant Vector that is C so here
1:17
we have a + b isal to B + a another
1:21
property of vector addition is that it
1:23
is associative that is the result of
1:26
adding vectors A and B first and then
1:29
adding Vector C is same as the result of
1:32
adding Vector B and C first and then
1:35
adding Vector a now consider two equal
1:38
and opposite vectors A and minus a as
1:42
shown in this figure now if we add these
1:45
two equal and opposite vectors their sum
1:48
would be equal to zero that
1:51
is
1:54
A+ minus
1:57
a is equals to
2:00
a -
2:02
A which is equals to0 this is because
2:05
the magnitude of these two vectors are
2:08
same but they have opposite directions
2:10
and the resultant Vector has zero
2:12
magnitude and is known
2:15
as null
2:17
Vector since null Vector has zero
2:19
magnitude we cannot specify its
2:22
direction now I would like to State one
2:24
more point about vector addition that is
2:26
when it comes to add vectors
2:29
representing phys physical quantities
2:30
like displacement here while drawing
2:33
diagram for addition of displacement
2:35
vectors you are not required to draw
2:38
vectors to their actual size it is often
2:40
convenient to use a scale in which the
2:43
distance on diagram is proportional to
2:46
the actual size for example in vectors
2:49
you can use 1 cm to represent 10 km just
2:52
as you do on the map you can use such
2:55
scales with other Vector quantities for
2:57
example in case of four you might to use
3:00
a scale in which 1 cm long Vector
3:03
represents a force of 5 Newton Now we
3:06
move on to subtraction of vectors
3:09
subtraction of two vectors can be
3:11
defined in terms of addition of vector
3:14
for this consider a case when we
3:17
multiply a vector uh say a by Min -1 so
3:21
-1 into a = to Min - A and this minus a
3:26
is by definition of vector that have the
3:29
same magnitude as Vector a but have
3:32
opposite direction so here the
3:33
difference of two vectors A minus B can
3:37
be defined in terms of sum of two
3:39
vectors A and minus B that is a - b is =
3:44
to a + minus B and we can use triangle
3:48
or polygon method of vector addition to
3:51
get our answers to understand
3:53
subtraction of two vectors let us
3:55
consider two vectors A and B as shown in
3:58
this figure now this figure also shows a
4:01
vector Min - B where Min - B is = to -1
4:08
B so as we stated earlier difference of
4:11
two vectors A and B would be equal to
4:14
the sum of two vectors A and minus B now
4:18
to obtain the difference we would Place
4:20
Vector minus B in such a way that its
4:24
tail is at head of vector a so this
4:27
figure shows both addition and sub
4:29
subtraction of vectors A and B for the
4:33
purpose of comparison here Vector R2 is
4:35
equal to a minus B which is the
4:37
difference between two vectors A and B
4:40
and Vector
4:42
R1 is equal to a + b which is the
4:45
addition of two vectors A and B next
4:48
thing I want to talk about in this video
4:50
is parallelogram method of vector
4:52
addition again to understand this method
4:54
of vector addition let us consider two
4:57
vectors A and B now to add vectors using
5:01
this method place the tail of vector B
5:04
so that it meets the tail of vector a as
5:07
shown in this figure in the next step
5:09
take these two vectors to be the first
5:12
two adjacent side of a
5:14
parallelogram and now draw the remaining
5:17
two sides in this figure dotted line
5:20
shows remaining two sides of the
5:22
parallelogram now to get the sum of
5:24
vectors A and B draw a vector that
5:28
extends from the tail of vector A and B
5:32
across the diagonal to the opposite
5:34
Corin of the parallelogram now in this
5:37
figure Vector o r shows the sum of
5:41
vectors A and B so
5:44
this o r is = to
5:48
R = to a + b sometimes it is common
5:52
error to draw some vectors as diagonal
5:55
running between tips of two Vector for
5:58
example vector Vector q p in this figure
6:03
this is incorrect it does not represent
6:05
the sum of two Vector in fact it
6:08
represent the difference that is a minus
6:10
B so we can use both triangle method and
6:13
parallelogram method to add vectors now
6:16
for more notes and study material you
6:18
can visit our website physics
6:20
catalyst.com
